Pcb Capacity Or Specify PCB Conveyor with 400 800mm Transmission Length and Min 0.6 Mm Board Thickness

Product Description:

The PCB Conveyor is an essential component for any PCB Transfer Machine, also known as a Printed Circuit Board Transporter. This conveyor system is designed to efficiently transport printed circuit boards within the assembly line, ensuring smooth and continuous production processes.

One of the key features of the PCB Conveyor is its versatility in handling different board thicknesses. With a minimum board thickness of 0.6mm, this conveyor can accommodate a wide range of PCBs, making it suitable for various manufacturing needs.

The transmission style of the PCB Conveyor is Conveyor and Driver Bar, providing a reliable and stable method of transferring PCBs along the assembly line. The combination of conveyor belts and driver bars ensures precise and controlled movement, minimizing the risk of damage to the boards during transportation.

With pitches available in 10mm, 20mm, and 30mm, the PCB Conveyor offers flexibility in configuring the spacing between boards, allowing for customized setups based on production requirements. Whether handling small or large PCBs, the conveyor system can be adjusted to accommodate different pitch sizes effectively.

When it comes to PCB capacity, the PCB Conveyor offers the flexibility to specify the desired capacity based on production needs. This customizable feature allows manufacturers to optimize the conveyor system according to the volume of PCBs being processed, ensuring efficient workflow and increased productivity.

For transmission length, the PCB Conveyor provides a length of 400+800mm, offering a total transmission distance of 1200mm. This extended length enables the conveyor system to cover a significant portion of the assembly line, facilitating the seamless transfer of PCBs between different stages of production.

In conclusion, the PCB Conveyor is a reliable and efficient solution for PCB Transfer Machines, serving as a critical component in the printed circuit board manufacturing process. With its adaptable design, precise transmission style, and customizable features, this conveyor system enhances production efficiency and streamlines PCB assembly operations.

Features:

• Product Name: PCB Conveyor
• Communication Mode: SMEMA
• Pitches: 10, 20, 30mm
• Body Structure: Strengthen Sheet-metal
• Transmission Style: Conveyor And Driver Bar
• Machine Dimension: 500 * 850 * 1250 Mm Or 600*960*1250mm

Technical Parameters:

Applications:

The PCB Conveyor is a versatile product designed for various applications in the electronics manufacturing industry. With its guide rail options for L-R or R-L movement, this conveyor system can efficiently transport printed circuit boards (PCBs) within a production line.

One of the key product attributes of the PCB Conveyor is its transmission length, which can be customized to 400+800mm to suit different production needs. This flexibility allows for seamless integration into different PCB transfer machines and conveying systems.

Furthermore, the machine dimensions of 500 * 850 * 1250mm or 600*960*1250mm make the PCB Conveyor suitable for compact spaces while offering ample space for PCB handling. The sturdy construction ensures reliability and durability in various working environments.

The PCB Conveyor operates at a frequency of 50Hz, providing consistent and reliable performance in production processes. Additionally, the communication mode of SMEMA enables seamless connectivity with other equipment in the production line, ensuring smooth workflow and efficiency.

Product Application Occasions and Scenarios:

- PCB Transfer Machine Integration: The PCB Conveyor is ideal for integrating into PCB transfer machines, allowing for smooth and efficient movement of PCBs between different manufacturing stages.

- PCB Conveying Machine Systems: The PCB Conveyor can be used as a vital component in PCB conveying machine systems, ensuring the continuous flow of PCBs for assembly and testing processes.

- Electronics Manufacturing Workstations: The versatile nature of the PCB Conveyor makes it suitable for use in electronics manufacturing workstations, providing a reliable solution for PCB handling and transportation.

Overall, the PCB Conveyor is a reliable and efficient solution for handling PCBs in various electronics manufacturing applications. With its customizable transmission length, guide rail options, and communication mode, this product is well-suited for enhancing productivity and workflow in PCB production environments.

Customization:

Product Customization Services for the Printed Circuit Board Conveyor:

Communication Mode: SMEMA

Pitches: 10, 20, 30mm

Application: SMT Production Line, for SMT Machine

Frequency: 50Hz

Transmission Length: 400+800mm

Product Attributes: Circuit Board Conveyor System, PCB Assembly Line Conveyor

Packing and Shipping:

Product Packaging:

The PCB Conveyor product is carefully packaged in a sturdy cardboard box to ensure safe transportation. Each component is securely wrapped and cushioned to prevent any damage during shipping.

Shipping:

Once packaged, the PCB Conveyor product will be shipped via a trusted courier service such as UPS or FedEx. Customers will receive a tracking number to monitor the delivery status of their order.
